7200 Product technical specification (TDS)

1. Product presentation:
Flufluoride TUW-7200 is a thermally stable, perfluorinated liquid used mainly as an industrial and conducting fluid. With excellent chemical inert, non-toxic, tasteless non-combustible, no flash point, low surface tension, excellent thermal conductivity,no VOC and other characteristics, can be used as electronic cleaning agent, precision cleaning agent, oil cleaning agent, cooling medium, air tightness test liquid,constant temperature fluid, extraction solvent, etc.

2. Product features:
 Low surface tension; low evaporation potential;
 Excellent material compatibility; moderate solubility;
 Excellent electrical insulation performance;
 Excellent thermal conductivity, thermal stability and chemical stability;
 Small viscosity change at low temperature;
 Dry to remove water, leaving no water marks;
 Liquid can be distilled and recycled, and reuse can reduce costs.
 Low environmental burden: colorless, tasteless, non-toxic, ozone depleting potential value of 0, low global warming potential coefficient
 No flash point

3. Product attributes:
 Boiling range: 76
 Appearance: Transparent liquid
 Color: colorless
 Dielectric constant: 7.3
 Dielectric strength: 40KV
 Surface tension: 13.63mN/m
 Density: 1.42 g/ml
 ODP: 0
 GWP: 297
 Specific heat: 25 C: 1.22 J / g C
 Pour point: -138
 Power viscosity (23 C): 0.41mpa.s
 Motion viscosity (23 C): 0.58mm2 / s
 Flash point: no
 Average molecular weight: 264

4. Product application scope:
(1) Cleaning: TUW-7200 electron fluoride liquid boiling point 75℃, strong solubility.It is suitable for gas-phase decontamination and wet cleaning. The TUW-7200
Company name: Shenzhen Huayi Brothers Technology Co., LTD Tel.: 0755-23737136
Office address: Huanan City Development Building, Pinghu Street, Longgang District, Shenzhen City
Factory address: Jieying Science Park, Bihu Avenue, Fenggang Town, Dongguan City electron fluoride solution has a low surface tension, and can penetrate into very small gaps in precision electrons, and the instrument provides a complete and thorough cleaning effect. Furthermore, the TUW-7200 electronic fluoride solution can be used alone or in combination with other solvents. This chemical liquid has good compatibility with most metals, plastic parts, and rubber materials.
(2) Thermal conductivity liquid: TUW-7200 electronic fluoride liquid liquid range is wide, the temperature range of negative 138℃ to 75℃. For the general industry or in the electronics industry. It is especially suitable for semiconductors, automatic test bench (ATE) and chips requiring low temperature control. The TUW-7200 electronic fluorinated liquid has low toxicity, is non-flammable, will not
destroy the ozone layer (ODP value =0), and is more environmentally friendly than the PFC.
(3) Solvent deposition: the TUW-7200 electronic fluoride liquid has the characteristics of low viscosity and low surface tension, s the TUW-7200  electronic fluoride liquid has the characteristics of high wetting and easy to flow. Therefore, the TUW-7200 electronic fluoride solution can effectively dissolve the additive lubricant required for the perfluoropolyether (PFPE) process.

5. Product storage and transportation:
This product shall be stored in a clean and dry warehouse to prevent high temperature and sunlight exposure, and stay away from heat source, acid, strong alkali, oxidizer and other TUW-7200 is a non-toxic, non-combustible, colorless and transparent liquid.
It is transported as a non-hazardous material. Transportation should be avoided during violent oscillation and inverted when stacking.

6. Product safety and precautions:
1) Normal local protection and industrial hygiene regulations on chemical treatmentmust be observed, and thermal decomposition products shall not be inhaled. Avoid skin exposure to high-temperature substances.
2) Do not eat, drink, or smoke when using this product. Clean up thoroughly after operation. Avoid the release into the environment. Avoid contact with oxidants(such as chlorine, chromic acid, etc.).
3) When using this product, follow the information and recommendations provided in our Chemical Safety Technical Manual. Basic precautions for the disposal of chemicals should also be in place
