1,1,2,2-tetrafluoroethyl-2,2,3,3-tetrafluoropropyl ether

Electronic fluorinated liquid

Shenzhen Huayi Brother Technology Co., Ltd

Product Introduction

(1) product name

a.Chemical name: 1,1,2,2-tetrafluoroethyl-2,2,3,3-tetrafluoropropyl ether

b.Product number:TUW-458

cCAS NO.16627-68-2

2Molecular formula and structural formula

  a.Molecular formula:C5H4F8O

          b.structural formula:



   c.molecular weight232.07


Physical property

project

index

project

index

appearance

Colorless Transparent Liquid

molecular weight

232

melting point °C

-94

dielectric constant

5.82

boiling point 760mmHg,°C

93.2

Specific heat capacity KJ/KgK

1.37

ODP

0

Dynamic viscosity cp

0.61

density 25°Ckg/m³

1533

dielectric strength Kv/mm

40

flash point °C















Quality index

Serial Number

item

unit

Technical Indicators

Superior products

Qualified products

1

exterior



Colorless, transparent, and free of mechanical impurities

Colorless, transparent, and free of mechanical impurities

2

purity

%

≥99.95

≥99.95

3

Moisture

%

≤0.0020

≤0.0050

4

acid value

ppm

≤10

≤10

5

Residue

ppm

≤100

≤100



Product usage

1,1,2,2-tetrafluoroethyl-2,2,3,3-tetrafluoropropyl ether can be used as an 1, as a cleaning agent, drying agent, and auxiliary agent for removing dust or non condensable gases. It can also be used as a raw material for synthesizing other products, electrolyte additives, etc.

Product packaging

This product should be packaged in a clean, dry, and free of other impurities storage tank. When packaging, it should be lined with a rubber cover and sealed tightly. Generally packed in 200L lined drums with a net content of 250kg per drum. If requested by the customer, packaging will be carried out according to their requirements.

Product storage

 This product should be stored in a cool and dry place away from heat sources, with good ventilation, and should not be exposed to sunlight or rain.



 Environmental policy



TUW will acknowledge and exercise the following responsibilities:

      Eliminate the possibility of pollution from the source anytime, anywhere

   Developing products with minimal environmental impact
