TUW-801 Hexafluoropropene Trimer CAS No. 6792-31-0

Electronic fluorinated liquid



TUW801 is a colorless, odorless, transparent liquid widely used in precision cleaning, solvent diluents, as well as in the preparation of polymers, synthesis of surfactants, etc.


Physical property

apparent

Clear, colorless

smell

tasteless

boiling point

110-120℃

molecular weight

450

Liquid density (25℃)

1.83g/L

flash point

None

surface tension

15mN/m

specific heat

1.014kJ/kg.℃

vapour pressure (20℃)

6.2kPa

kinematic viscosity (25℃)

1.321cst

Heat of vaporization

37kJ/mol

dielectric constant

2.07

Coefficient of body expansion (25℃)

0.0014

Dielectric loss (10MHz)

0.03

ODP

0

resistivity

≧1*10^14 Ω·mm

Ω·mm

GWP

120

Dielectric strength

>32kV



Product Features
Features: colorless, odorless, non-toxic, safe, non flammable, mild solubility, insoluble in water, good thermal stability, high density, low surface tension, low viscosity, low latent heat of evaporation, excellent material compatibility.
Advantages: environmentally friendly and clean, safe to use, good insulation performance, no damage to electronic precision equipment, and no damage to electronic components and circuits. Through distillation and regeneration, the amount of industrial waste is greatly reduced, and the effect of rapid drying can be achieved.

Product Usage Scope
1. Dissolve various perfluoropolyether compounds as solvents;
2. Liquid leakage on the side of electronic components, air tightness testing of electronic components (IC, LSI components) or electronic devices;
3. Live cleaning equipment and insulating liquid;
4. Electronic precision cleaning, optical cleaning, dehydration cleaning;
5. Heat transfer fluid and cooling medium;
6. Hydraulic transmission fluid, sealing and isolating fluid for electronic equipment;
7. Solvent diluents, lubricant diluents, special purpose solvents, etc;

Product storage and transportation
1. TUW-801 should be stored in a clean and dry warehouse, protected from high temperatures, sunlight, heat sources, acids, strong alkalis, oxidizing agents, etc.
2. TUW-801 is a non-toxic, nonflammable, colorless, and transparent liquid that is transported as a non hazardous material. During transportation, avoid violent vibration, and avoid stacking upside down.。

Product safety and precautions
1. Local regulations regarding the normal protection of chemical handling and industrial hygiene must be observed, and thermal decomposition products must not be inhaled. Avoid skin contact with hot substances.
2. Do not eat, drink, or smoke when using this product. Thoroughly clean after operation. Avoid release to the environment. Avoid contact with oxidizing agents (such as chlorine, chromic acid, etc.).
3. When using this product, the information and recommendations provided in TUW will acknowledge and exercise the following

responsibilities:
• Eliminate the possibility of pollution from the source anytime, anywhere
• Develop products with minimal environmental impactour Chemical Safety Data Sheet should be followed. There should also be basic preventive measures needed to handle chemicals.

Company  name:  Shenzhen Huayi Brother Technology Co., Ltd
Office  address:  South China city development building, Pinghu street, Longgang District, Shenzhen
Factory address: jieying Technology Park, Bihu Avenue, Fenggang town, Dongguan
Tel: 0755-23737136
